2000kg Vertical Plastic Particle Mixer

Name: 2000kg Vertical Plastic Particle Mixer
SKU: N/A

Rated loading capacity: 2000kg (bulk density of plastic particles calculated at 0.6~0.8g/cm³)
Effective mixing volume: Approximately 3000~3200L
Mixing uniformity: ≥98%
Single mixing time: 10~18min (adjustable according to material characteristics)

Send Inquiry

Product Description

2000kg Vertical Plastic Particle Mixer - Industrial Mixing Solutions

The 2000kg Vertical Plastic Particle Mixer from Shandong Yude Plastic Machinery delivers exceptional performance for large-scale plastic processing operations. This industrial-grade blender proficiently handles virgin tars, regrind materials, color masterbatches, and added substances in clusters up to 2 metric tons. Your generation line will advantage from steady fabric homogenization and decreased preparing time.

Why Choose Our Vertical Plastic Particle Mixer?

Our vertical mixing technology addresses critical challenges in plastic manufacturing. You'll eliminate color streaks from uneven masterbatch distribution. Material stratification becomes a thing of the past. The unique fountain circulation effect lifts materials from bottom to top, creating uniform dispersion throughout the mixing chamber.

Key Performance Features

Superior Mixing Technology

The centrally mounted spiral auger creates continuous vertical circulation. Materials lift from the bottom and cascade down in an umbrella pattern. This action breaks agglomerates and ensures uniform blending. Your mixing uniformity reaches ≥98% with every batch.

Space-Efficient Design

The vertical configuration saves valuable floor space compared to horizontal mixers. You can install this equipment in facilities with limited layout flexibility. The heavy-duty stainless steel frame minimizes vibration during operation.

Hygienic Construction Standards

All material contact surfaces use 304 stainless steel construction. You get excellent corrosion resistance and easy cleaning capabilities. Material contamination risks are minimized through smooth surface design.

2000kg Vertical Plastic Particle Mixer

Technical Specifications of 2000kg Vertical Plastic Particle Mixer

Parameter	Specification
Rated Loading Capacity	2000kg (bulk density 0.6-0.8g/cm³)
Effective Mixing Volume	3000-3200L
Mixing Uniformity	≥98%
Single Mixing Time	10-18 minutes (adjustable)
Motor Power	7.5-11kW
Power Supply	380V/50Hz/3-phase
Drum Dimensions	Dia. 1600mm × H 2000mm
Material Contact Parts	304 Stainless Steel
Mixing Speed	250-350 RPM
Noise Level	<80dB

2000kg Vertical Plastic Particle Mixer

Industrial Applications

Plastic Manufacturing Plants

You can efficiently blend virgin resins with recycled materials. Color masterbatch distribution becomes uniform throughout the batch. Additive incorporation reaches consistent ratios even at 1:1000 proportions.

Injection Molding Operations

Large automotive components require structural uniformity. PP and ABS blending with strengthening fillers prevents localized weakness. Your finished products maintain consistent quality standards.

Extrusion Processing

PVC and PE pipe production benefits from uniform filler distribution. Calcium carbonate mixing prevents die blockages. Material flow remains consistent throughout the extrusion process.

Recycling Facilities

Mixed plastic flakes achieve standardized melt flow index. Various source materials homogenize effectively. Your recycled products meet quality specifications for resale.

The 2000kg Vertical Plastic Particle Mixer handles materials with different bulk densities without segregation. Static charge buildup doesn't affect mixing performance. Your operation maintains consistent output quality.

2000kg Vertical Plastic Particle Mixer

Safety and Control Features

Integrated Protection Systems

Overload and overheat protection
Automatic timer controls
Emergency stop functionality
Sealed discharge gate operation

User-Friendly Operation

Manual hopper feeding accommodates various loading methods. Pneumatic conveying systems integrate seamlessly. The stainless steel discharge gate operates smoothly for complete material removal.

Optional Enhancement Features

Heating jacket for simultaneous drying
PLC control systems
Dust extraction ports
Reinforced drum construction

Quality Assurance

Shandong Yude Plastic Machinery maintains strict quality control throughout production. Professional personnel inspect every component from raw materials to finished equipment. Your mixer meets CE mechanical directives and ISO 9001 manufacturing standards.

Our technical team provides rapid product iteration capabilities. Industry trends are captured and implemented quickly. Customized solutions address your specific material requirements efficiently.

Customer Support Services

24/7 Technical Assistance

Professional customer service teams answer equipment questions promptly. Emergency solutions are provided when operational issues arise. Your production downtime is minimized through quick response protocols.

Comprehensive Service Network

Domestic service outlets provide 24-hour on-site response. International partnerships ensure overseas customer support. Equipment information and service records are tracked for efficient problem resolution.

Training and Documentation

Operating manuals include detailed maintenance procedures. Technical training ensures proper equipment operation. Your staff gains confidence in mixer operation and troubleshooting.

When you choose our product, you're investing in proven mixing technology. Years of development have refined this equipment for demanding industrial applications. Your production efficiency improves while maintaining consistent product quality.

2000kg Vertical Plastic Particle Mixer

Frequently Asked Questions

Q: Can the mixer handle powder additives along with granules?

A: Standard units work best with granular materials. Powder content above 10% may require specific modifications. Sealed bearings and dust filtration systems accommodate high-powder applications.

Q: What is the typical cleaning time for color changes?

A: Proper access features reduce cleaning time to 60-90 minutes. Side-access manholes and removable discharge gates facilitate thorough cleaning. Air-purge ports help remove residual materials.

Q: How does energy consumption compare to separate heating equipment?

A: Combined mixing and heating reduces energy costs by 15-20%. Double-layer insulation improves thermal efficiency. Friction heat from mixing contributes to overall energy savings.

Q: What materials can cause excessive screw wear?

A: Glass-filled plastics and abrasive recycled content increase wear rates. Standard polyolefins allow 10+ year screw life. Hardened steel coatings extend service life for abrasive materials.

Q: Is the mixer suitable for moisture-sensitive materials?

A: The unit effectively removes surface moisture and pre-heats materials. Extremely hygroscopic plastics may require additional dehumidifying equipment. Dry-air generator attachments are available for specialized applications.

Contact Us

Ready to improve your plastic mixing operations with the 2000kg Vertical Plastic Particle Mixer? Contact our technical team to discuss your specific requirements. We provide customized solutions for your production needs.
